Oil resistant oil proof : Oil resistant type
Sensing type : Through beam type
Sensing distance : 15 m
Sensing target : Opaque material min Ø 12 mm
Light source : Infrared LED 850 nm
Response time : Max 1 ms
Power voltage : 10 to 30 VDC ±10% ripple P P max 10 %
Current consumption : Emitter Receiver max 20 mA
Sensitivity adjustment : Sensitivity adjuster
Operation mode : Light ON Dark ON set by switch
Control output : PNP open collector
Connection type : Ø 4 mm 3 wire 300 mm emitter of through beam type Ø 4 mm 2 wire 300 mm M12 connector AWG 26 core diameter 0 52 mm number of cores 20 insulator out diameter Ø 1 mm
Environment Ambient illumination : Sunlight max 11000 lx Incandescent lamp max 3000 lx received illumination
Environment Ambient temperature : -25 to 60 ℃ storage -40 to 70 ℃
Protection structure : IP67 IEC standard IP67G JEM standard
Environment Ambient humidity : 35 to 85 % RH storage 35 to 85 % RH
Material : Case acrylonitrile butadiene styrene LED cap PA12 lens cover polymethyl methacrylate acrylic
Accessories : Mounting bracket M3 bolt 4 adjustment screwdriver
Weight : Approx 105 g approx 55 g
