• Sensing Type: Diffuse reflective type
• Sensing Distance: 100 mm
• Sensing Target: Opaque, Translucent material
• Response Time: Operation: Max. 3 ms, Return: Max. 100 ms
• Light Source: Infrared LED
• Sensitivity Adjustment: Sensitivity adjuster
• Operation Mode: Light ON
• Weight: Approx. 75 g (Approx. 38 g)
• Power Voltage: 12–24 VDC ±10% (Ripple P-P: Max. 10%)
• Current Consumption: Max. 35 mA
• Control Output: NPN open collector
• Ambient Illumination: Sunlight: Max. 11,000 lx, Incandescent lamp: Max. 3,000 lx (received illumination)
• Ambient Temperature: -20 to 65 °C, Storage: -25 to 70 °C
• Ambient Humidity: 35 to 85% RH, Storage: 35 to 85% RH
• Protection Structure: IP50
• Connection Type: Cable type (Ø3.5, 2 m)
• Material: Case: PC, Sensing part: PC, Bracket: SPCC, Bolt: SCM, Nut: SCM, Sleeve: Brass, Ni-plated
