Detection range : 103 mm
Detection object distance : 0.5 ~ 3.0 mm
Function : Positioning
Detection type : Inductive
Linearity : ±400 µm
Response time : ≤ 30 ms
Power voltage : 15 ~ 30 VDC, Rated voltage : 24 VDC
Output specification : 0–10 VDC / 4–20 mA
Load resistance : Voltage ≥ 2000 Ω, Current ≤ 500 Ω
Current consumption : ≤ 30 mA
Insulation resistance : ≥ 100 MΩ (500 VDC megger)
Dielectric strength : 500 VAC, 50 / 60 Hz for 1 min
Vibration : 1.0 mm double amplitude at 10 ~ 55 Hz in X, Y, Z directions for 30 min
Shock : Half sinus 30 g, 11 ms (EN 60068-2-27)
Protection circuit : Output short circuit protection, over current protection, reverse polarity protection
Ambient temperature : -25 ~ 85°C (Storage : -25 ~ 85°C, no freezing or condensation)
Ambient humidity : 35 ~ 85 %RH (Storage : 35 ~ 85 %RH, no freezing or condensation)
Protection structure : IP67 (IEC standard)
Standard detection object material : Structural steel (SS275, SM45C, etc.)
Material : Housing, sensing part : PBT
Connection : Connector type
Connector : M12 4-pin plug
Unit weight (packaged weight) : ≈53.5 g (≈79 g)
