Festo LOE-D-MAXI – Proportional Mist Lubricator

The Festo LOE-D-MAXI is a proportional mist lubricator from the D series, Maxi size, designed to deliver precise oil mist lubrication in compressed air systems. With a 190 cm³ oil capacity, metal bowl guard, and operating pressure range up to 1.6 MPa (16 bar), it’s built for reliable performance across a -10°C to 60°C temperature range, with RoHS-compliant materials and VDMA24364 LABS conformity for clean, oil-controlled pneumatic applications

Technical Specifications

• Model : 192577
• Series: D
• Size: Maxi
• Design: Proportional Standard Mist Lubricator
• Mounting Position: Vertical ±5°
• Mounting Type: With accessories
• Max. Oil Capacity: 190 cm³
• Bowl Guard: Metal
• Operating Pressure: 0–1.6 MPa / 0–16 bar / 0–232 psi
• Min. Flow Rate (for lubricator function): 10 l/min
• Operating Medium: Compressed air per ISO 8573-1:2010 [7:4:4], or inert gas
• Air Purity Class at Output: ISO 8573-1:2010 [7:4:-]
• Corrosion Resistance Class: CRC 2 – Moderate
• LABS (PWIS) Conformity: VDMA24364-B1/B2-L
• Media Temperature: -10°C to 60°C
• Ambient Temperature: -10°C to 60°C
• Storage Temperature: -10°C to 60°C
• Product Weight: 1100 g
• Material Note: RoHS Compliant
