IMI Herion 80107 Series Solenoid Valve | G1/4, 3/2 NC

The IMI Herion 80107 series NAMUR interface solenoid valve is designed for compressed-air control applications. It features 3/2-way normally closed operation, solenoid pilot actuation with air spring return, G1/4 ports, and an aluminium body with NBR seals.

Technical Specifications

• Brand: IMI Herion

• Series: 80107

• Product Type: NAMUR Interface Solenoid Valve

• Valve Operation: 3/2-way

• Function: Normally Closed (NC)

• Actuation: Solenoid pilot / air spring return

• Medium: Compressed air

• Port Size: G1/4 NAMUR

• Operating Pressure: 2–8 bar (29–116 psi)

• Operating Temperature: -10°C to +50°C

• Flow Rate: 1325 l/min (47 scfm)

• Power Consumption: 2.7 W

• Body Material: Aluminium

• Seal Material: Nitrile Rubber (NBR)
