MEAN WELL XLG-150-L-A LED Driver – 150W

The MEAN WELL XLG-150-L-A is a 150W constant-power LED driver designed for industrial and outdoor LED lighting applications. It accepts a wide 100–305VAC / 142–431VDC input and provides 120–214V DC output with adjustable output current. The enclosed IP67 design provides reliable operation in demanding environments.

Technical Specifications

• Brand: MEAN WELL
• Series: XLG-150
• Model: XLG-150-L-A
• Part Number: XLG-150-L-A
• Part Number Alias: XLG-150-L-A-PH
• Product Type: LED Power Supply / LED Driver
• Operation Mode: Constant Power (CP)
• Rated Output Power: 150W
• Number of Outputs: 1
• Default Output Current: 700mA
• Output Current Range: 700–1050mA
• Adjustable Current Range: 350–1050mA
• Output Voltage: 120–214V DC
• Input Voltage: 100–305V AC
• Input Voltage: 142–431V DC
• Input Frequency: 47–63Hz
