| Parameter | Specification |
|---|---|
| Brand | Pepperl+Fuchs |
| Model Number | KFD2-UFC-Ex1.D |
| Product Type | Frequency Converter with Trip Values (1-Channel Isolated Barrier) |
| Product Range | K-System |
| Input Type | NAMUR Sensors or Dry Contacts |
| Input Frequency Range | 1 mHz … 5 kHz |
| Output | Current Output, 0/4 mA … 20 mA (Freely Adjustable) |
| Relay Outputs | 2 Relay Contact Outputs |
| Transistor Output | 1 Potential-Free Transistor Output |
| Configurable Output Functions | Trip Value Display (Min/Max Alarm), Serially Switched Output, Pulse Divider Output, Error Signal Output |
| Display | Built-in LCD with Selectable Physical Units |
| Status Indication | LED Indicators for Fault and Output Status |
| Configuration Method | Keypad or PACTware Software |
| Start-Up Override | Yes |
| Diagnostic Features | Line Fault Detection (LFD) |
