| Parameter | Specification |
|---|---|
| Brand | Pepperl+Fuchs |
| Model Number | NBN40-U1-A2 |
| Product Type | Inductive Proximity Sensor |
| Sensor Head | Bidirectional and Rotatable |
| Rated Operating Distance (sn) | 40 mm |
| Assured Operating Distance (sa) | 0 … 32.4 mm |
| Installation | Non-Flush |
| Switching Function | Complementary |
| Output Type | PNP, 4-Wire |
| Output Polarity | DC |
| Operating Voltage | 10 to 30 V DC |
| Switching Frequency | 0 to 180 Hz |
| Indicators | 4 × LED (Green: Power, Yellow: Switching), 360° Visibility |
| Reverse Polarity Protection | Yes |
| Short-Circuit Protection | Pulsing |
| Housing Material | PA / Metal with Epoxy Powder Coating |
| Sensing Face Material | PA |
| Housing Base | Plastic |
| Dimensions | 40 × 40 × 120 mm |
| Connection Type | Screw Terminals, Up to 2.5 mm² |
