Phoenix Contact – QPD P 4PE2,5 6-11 BK Connector

• 5-position connector (4+PE)
• Rated voltage: 690 V AC/DC
• Rated current: 20 A
• Supports 1 mm² to 2.5 mm² wires
• IDC connection for quick and easy wiring
• Cable size: 6–11 mm diameter
• High surge voltage up to 8 kV
• Low contact resistance (< 4 mΩ)
• Strong PA housing with NBR seal
• Silver-plated contacts for better conductivity
• IP66 / IP68 / IP69K protection
• UV and impact resistant (IK07)
• Black housing (RAL 9005)
• Works in -40°C to +100°C temperature
• Durable with up to 50 mating cycles
