Phoenix Contact SACC-VB-3CON-M16/A-1L-SV 230V
Description
- Type: Valve Connector (Type A)
- Application: Universal / Solenoid valve connection
- Positions: 3
- Connection Type: Screw connection
- Cable Entry: M16 (6 – 8 mm cable diameter)
- Voltage: 230 V AC/DC
- Current: 1.5 A
- Protection: IP65
- Status Indicator: LED (Yellow)
- Protection Circuit: Built-in varistor (surge protection)
- Material: PA housing, CuZn contacts (CuSn plated), NBR seal
- Contact Resistance: ≤ 4 mΩ
- Insulation Resistance: > 2 GΩ
- Dimensions: 27.9 mm (W) × 33.2 mm (H) × 40 mm (L)
- Conductor Size: 0.25 – 1.5 mm² (AWG 24–16)
- Temperature Range: -25°C to +60°C
