• Type: Valve Connector (Type B – 10 mm)
• Application: Universal / Solenoid valve connection
• Positions: 3
• Connection Type: Screw connection
• Cable Entry: M16 (6 – 8 mm cable diameter)
• Voltage: 110 V AC/DC
• Current: 1.5 A
• Protection: IP65
• Status Indicator: LED (Yellow)
• Protection Circuit: Built-in varistor (surge protection)
• Material: PA housing, CuZn contacts (CuSn plated), NBR seal
• Contact Resistance: ≤ 4 mΩ
• Insulation Resistance: > 2 GΩ
• Dimensions: 21 mm (W) × 33.2 mm (H) × 40.5 mm (L)
• Conductor Size: 0.25 – 1.5 mm² (AWG 24–16)
• Temperature Range: -25°C to +60°C
