Schneider Electric STD100-150 Duct Temperature Sensor

Schneider Electric STD100-150 is a duct temperature sensor designed for temperature monitoring in HVAC and building automation systems. It features a 150 mm sensor length, an aluminum flange, a 20 mm cable fitting, and an IP65 protection rating. It is suitable for applications requiring temperature measurement across a wide temperature range.

Technical Specifications

• Brand: Schneider Electric

• Model: STD100-150

• Part Number: 5123006010

• Product Type: Duct Temperature Sensor

• Compatibility: TAC Vista

• Cable Fitting: 20 mm

• Time Constant: 52,000 ms at 3 L/min; 72,000 ms at 1.5 L/min

• Sensor Length: 150 mm

• Flange Material: Aluminum

• Temperature Range: -40°C to +150°C

• IP Rating: IP65
