Schneider STD500-150 Duct Temperature Sensor 150mm

Brand: Schneider Electric
Part No.: STD500-150
Duct temperature sensor, STD500 series
Sensor type: NTC 10 kΩ thermistor (T3) at 25°C
Immersion tube length: 150 mm
Device application: duct / HVAC air duct temperature measurement
Output type: analog
Measurement accuracy: ±0.2°C (0…25°C range)
Time constant: 52,000 ms at 3 l/min / 72,000 ms at 1.5 l/min
Protection rating: IP65
Compatible with Schneider Electric Continuum building automation system
Mounting support: duct side mounting
Connection: screw terminals, wire AWG 24…AWG 18
Housing materials: Mounting flange: aluminium, Connection box: PA (polyamide), Immersion tube: stainless steel
Housing colour: black and green
Dimensions: 65 mm (W) x 84 mm (H) x 44 mm (D)
Weight: 0.12 kg
Product certifications: CE
Standards: EN 50082-2 / EN 50081-1
Targeted region: Asia Pacific / Europe
Suitable for plant room and HVAC duct installations requiring precise temperature monitoring
Packaging: individual unit (PCE), bulk pack of 40 units (BB1)
